Digital Inkjet Corrugated Box Printer 25-8PH



Digital inkjet corrugated box printer with auto feeder and belt vacuum printing table is mainly used in corrugated cardboard box printing. It installed eight pieces of digital printing heads. It is CMYK 4 colors water based ink system.



Model	25-8PH
Software	Maintop, Xprint software
Picture format	TIF, PDF, JPG
Printing head	Epson
The quantity of printing head	8 heads
Max printing width	270mm
Max printing speed	700m2/hour(1pass), 350m2/hour(2pass)
Printing resolution	360*600DPI (1pass), 360*1200DPI(2pass)
Printing color	CMYK-4 colors
Indoor temperature	15-28℃
Humidity	20%-70%
Max board feeding size	2500x1600mm (manual 2500x4000)
Min board feeding size	650x350mm
Max printing size	2460x1560mm
The thickness of corrugated	1.5-15mm
Operation system	Windows 7/10
Air supply	Max 1.0Mpa
Total power	4.9KW
Voltage supply	220V, 50HZ, single phase, 3 lines
Machine weight	2500kgs
Machine dimension	4400x2800x1780mm
