| Categories | LED Curtain Screen |
|---|---|
| Place of Origin: | Guangdong, China (Mainland) |
| Brand Name: | Singheng |
| Model Number: | P20 |
| Price: | USD+To be negotiated+square meter | 1 Piece/Pieces (Min. Order) |
| MOQ: | 1 Piece/Pieces |
| Certification: | CE RoHS UL FCC |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 3000+square meter+per month |
| Delivery Time: | About 16 days |
| Packaging Details: | Plywood case |
| Usage: | Outdoor |
| Tube Chip Color: | Full Color |
| Pixels: | 20mm |
| pixels per sqm: | 2500 |
| Best viewing distance: | >=22m |
| input voltage: | AC110/220V |
| Average Power consumption: | ≤120W/㎡ |
| Max.Power consumption: | ≤300W/㎡ |
| working temperature: | _40℃~+50℃ |
| brightness: | 7500CD/㎡ |
| Company Info. |
| Shenzhen Singheng Optoelectronics Co., Ltd. |
| Verified Supplier |
| View Contact Details |
| Product List |
P20 Panel Transparent Outdoor Grille Led Display Advertising LED Billboard
1. IP67 high protection level. The concept of IP67 is soaking and waterproofing, that is, the overall immersion of the product.
2. Light weight and low wind load. The light weight is due to the screen grid, which makes the LED display transparent, so its wind load capacity is extremely strong.
3. LED curtain screen is a kind of LED screen composed of light bars, also called LED light bar screen. Mainly used in outdoor walls, glass curtain walls, building tops and other fields.
4. It is suitable for the construction of super large outdoor display, which is the first choice for creating landmark dynamic display landscape.
5. Easy to install and easy to maintain. It is installed without steel structure and does not require air conditioning.
6. High performance and low power consumption. The real energy saving comes from: high-brightness, high-efficiency LED lights, high conversion efficiency power supplies.
P20 FULL-COLOR TECHNICAL PARAMETER | |
|---|---|
Item | Parameter |
Pixel Pitch | 20mm |
Pixel Density | 2500dot/sqm |
Pixel Configuration | 2R1G1B DIP346 |
Module Size | 320*160 mm |
Module Resolution | 16*8 dot |
Cabinet Resolution | 12*56 dot |
Cabinet Size | 960*1120 mm |
Weight | |
Cabinet Material | SPCC |
Viewing Distance | ≥20 m |
Viewing Angle (Horizontal Axis) | 120° |
Viewing Angle (Vertical Axis) | 80° |
Refresh Rate | >600Hz |
Grey Scale | 65536 |
Brightness | ≥8000cd/m2 |
Max Power Consumption | 700 w/sqm |
Average Power Consumption | 2500 w/sqm |
Drive Mode | static |
Signal EMC | VGA,DIV,HDMI,SDI |
Signal Transmission Mode | 568B |
Network Cable | ≤100m, Multimode |
Control Distance | optical fiber≤500m, Single mode optical |
fiber | ≤20 kilometer |
Lifespan | ≥10,0000 h |
Waterproof Grade | Outdoor Use Only |
Input Voltage | AC220V±10% 50-60HZ |
Celsius | Degree:—10℃-40℃ |
humidity:10 | 10—85%RH |
Q1:LED display models are generally expressed in PX, such as P2 P3
P4.....P8, P10, what does this mean?
A: P2 P3 P4.....P8,P10 means that the pixel pitch is 2mm 3mm
4mm....8mm,10mm, which determines the number of
pixels per unit area of a display, so it represents the clarity of
the display.The smaller the pitch, the
higher the clarity. Usually, the models of indoor full color
display are: P1.667, P1.875, P2.5, P3, P4, P5,
P6, P7.62, P10. Outdoor full color display are P4, P5, P6, P7, P8,
P10, P16, P20, P25, P31.25 etc.
Q2:Is it OK to print my logo on your product?
A:Yes,We support OEM and ODM services .
Q3: To order a display ,What kind of information do I have to offer you?
A:You should provide width/height of
the display, the main use, the viewing distance, the scene photos,
special requirements,then I can provide
you with a detailed list of quotations. Sometimes you should also
provide information such as display
orientation, geographical location, local climate, and so on.
Q4:How to install?
A:Free of charge to provide detailed steel structure drawings and
installation guidance and wiring diagram,
free remote debugging. We can also send our engineers to the site
to guide the installation.
Q5:How long is the transportation time?
A:Shipping: 20-30 days,Airlift: within 3-7 days.Q6:What about your quality?
A:The quality of our display is excellent. We use the materials of
high quality suppliers in the world,
strictly control the production process, and pass the multiple
quality inspection to ensure that every
product is qualified.
|
Static Drive Mode LED Curtain Screen P20 Panel 2500 W/Sqm Average Power Consumption
