| Categories | Solid Lubricant Bearings |
|---|---|
| Brand Name: | BRAND CHINA REPLACMENT OILES 500 GUIDE BUSHINGS |
| Model Number: | CCylindrical manganese bronze bushes, tin bronze flanged bushes, aluminium bronze bushes, thrust washers, wear plate |
| Certification: | SEA430B,C86300,DIN1709,FIBRO |
| Place of Origin: | Manufactured in China |
| MOQ: | 300 Piece/Pieces (Min. Order) |
| Price: | $0.10 - $3.00 / Pieces |
| Payment Terms: | TT IN ADVANCE,L/C,Western Union |
| Supply Ability: | 1000000 Piece/Pieces |
| Delivery Time: | 2-4 weeks |
| Packaging Details: | EXPORT CARTONS |
| Material: | Aluminum-Bronze With Solid Lubricant,manganese bronze alloy bushes, tin bronze flanged bushes |
| Feature: | Self lubrication |
| Lubrication: | Graphite,self-lubricating bushing |
| Application: | Mediate Load But Higher Temperature And Condition With Mediate Running Velocity Etc. |
| Standard Size: | Daido metal bushing, |
| Bronze: | C86300,C95400,C93200 BRONZE BUSHINGS |
| Features: | Low Resistance, Long Operating Life, Maintenance, guide, High precision |
| Company Info. |
| JIAXING VIIPLUS INTERNATIONAL TRADING CO.,LTD |
| Verified Supplier |
| View Contact Details |
| Product List |
C86300 (SAE430B) Manganese Bronze / C863 Manganese Bronze Bushing & Wear Plate
Broze plugged graphite sleeve bushings — C86300 Manganese Bronze sliding bearings SAE 430B
VIIPLUS CHINA self-lubricating bearing products have been supplied in chassis walking mechanism, body parts, hydraulic components and other parts.It consists of bimetallic boundary lubricated rolling bearings, metal-based self-lubricated bearings and metal-plastic self-lubricated rolling bearings.These bearing materials have excellent wear resistance and dust resistance under high load conditions. Meanwhile, self-lubrication technology greatly lengthened the maintenance cycle of the bearing, improved the utilization rate of the equipment and reduced the maintenance cost.
BRONZE BUSHES ASSEMBLY
VIIPLUS Manufacturer of quality STANDARD-STOCKED SIZE cast bronze sleeve bushing C86300 Manganese bronze bushes sliding bearings.
VIIPLUS is an China manufacturer of self-lubricating bearings,C86300 brass, bronze bushings, as well as manganese bronze bushing,aluminum bronze plain bearings, tin bronze bronze bushings.
Brass, Bronze Bushings & & Aluminum Bronze - Metal Bushings Made in China
SLIDING BEARINGS TOLERANCE
To the H9 tolerance of the slide bearing we recommend shafts with tolerance e7 or f7. If h-shafts are used, the bearing inner diameter should be machined up to tolerance F7.
OUR SLIDING BEARING PRODUCTS ARE ENGINEERED TO EXACTING STANDARDS
SIZE
VIIPLUS china products are manufactured for precise standards for
long-term usage and high output. Made from C95400 aluminium bronze
bushing, C86300 manganese bronze alloy bushes,C93200(SAE660) tin
bronze flanged bushes,copper alloy or other properties, our
products can take your designs to the next level. We can even
custom manufacture a bearing for your specific needs.VIIPLUS offers
a versatile product bushing made from many types of materials for
improved performance in each unique applications.
Aluminum bronze Bushings, brass bronze copper alloy, bronze alloys, bronze bar stock, manganese bronze, C86300, C93200, C95400, SAE40, SAE660 Broze Bushing VIIPLUS from china supply Cylindrical bushes, flanged bushes, thrust washers, flat strip material, half bearing, wear plate.
The extensive applications of sliding bronze bearings are as follows
Plug Graphite Sleeve Bushing
JDB solid insert bearing series Is the general basic product,
regardless of high pressure, low pressure, high temperature, low
temperature, oil lubrication, no oil lubrication or water
lubrication, can adapt.The matrix of the product is high force
brass, hardness than general copper sleeve increases one time,
wear-resisting property increases one time above.
Widely used in: light industrial machinery, heavy machinery,
construction machinery, metallurgical machinery, transport
machinery, such as: continuous casting machine, rolling mill,
injection molding machine, paper machine, mold guide column, ship,
machine tools and so on.
Spare parts bushings for imported agricultural equipment - application of Self lubricating bearing such as plough bushes, rake, planter bearings, cultivator bushing, deep soil machine bushings, combine harvester bearings, tractor bushes, etc
VSB-50 Solid Bronze Metallic Self-lubricating Bearings C86300 Manganese Bronze Bushings
C86300 Typical applications include slow speed heavy duty load bearings, gears, cams and hydraulic cylinder parts.continuous cast manganese bronze is a high strength, non-heat treatable copper alloy intended for use in applications requiring a good combination of outstanding wear characteristics and high bearing strength for heavy loads and slow speeds.
Self-lubricating bearings are divided into composite
self-lubricating bearings, solid embedded self-lubricating bearing
shaft, bimetallic self-lubricating bearings, special
self-lubricating bearings, according to different USES and working
conditions, choose different self-lubricating bearings.
One of the major categories of solid inlaid self-lubricating
bearings (JDB) is a new type of lubricating bearings with both the
characteristics of metal bearings and non-oil lubricated bearings.
It has the characteristics of high bearing capacity, impact
resistance, high temperature resistance, strong self-lubricating
ability, especially suitable for heavy load, low speed,
reciprocating or oscillating and other occasions where it is
difficult to lubricate and form oil film, and is not afraid of
water and other acid corrosion and erosion.Products have been
widely used in metallurgical continuous casting machine, rolling
equipment, mining machinery, mold, lifting machinery, textile
machinery, wind power generation, ships, turbines, turbines,
injection molding machine and equipment production lines.Wear
resistance is double that of the common shaft sleeve.
VSB-50 material is made of strong cast bronze based metal with special
solid lubricants embedded. The base metal withstands high load and
the solid lubricants provide self-lubrication. The bearing shows
excellent performance without pre-lubrication under conditions of
extreme high/low temperature with low speed. This material provides
a maintenance-free bearing solution, particularly for high load,
intermittent of oscillating motion.
Tech. Data | ||||
Grade | 650# | 650S1 | 650S2 | 650S3 |
Material | CuZn25AI5Mn4Fe3 | CuSn5Pb5Zn5 | CuAI10Ni5Fe5 | CuSn12 |
Density | 8 | 8.9 | 7.8 | 8.9 |
Hardness | ≥210 | ≥70 | ≥150 | ≥75 |
Tensile strength | ≥750 | ≥250 | ≥500 | ≥270 |
Yield strength | ≥450 | ≥90 | ≥260 | ≥150 |
Elongation | ≥12 | ≥13 | ≥10 | ≥5 |
Coefficient o linear expansion | 1.9×10-5/℃ | 1.8×10-5/℃ | 1.6×10-5/℃ | 1.8×10-5/℃ |
Max.Temp. | -40~+300℃ | -40~+400℃ | -40~+400℃ | -40~+400℃ |
Max.dynamic load | 100 | 60 | 50 | 70 |
Max.speed(Dry) | 15 | 10 | 20 | 10 |
N/mm²*m/s(Lubrication) | 200 | 60 | 60 | 80 |
Compression deformation | < 0.01 mm | < 0.05mm | < 0.04mm | < 0.05mm |
This kind of bearing can be applied under dry, high temperature, high pressure, corrosive, water or other chemical environments when no oil can be introduced. It is widely used in automotive products line, water engineering, dam gate, plastic industries, successive casting machines, steel rollers in metallurgy industry, mineral machines, ships, turbo generators, hydraulic turbines and injection molding machines...Your recognised global partner for sliding bearing applications China Bearing Technologies
